Automatic Painting Machine
Batch Automatic Painting Machine
automatic painting machine
Axis Painting Machine
Autocoat Engineering (I) Pvt. Ltd. is already in manufacturing of painting plant on Turn Key Basis having supplied many large Spray Painting Booth & Conveyorised Phosphating & Painting plant all over India, Bahrain, Dubai, Saudi Arabia, Egypt etc.
To increase productivity, reduce cost of painting, Automatic Spray Painting System are designed, developed in Japan, Taiwan & China and are extremely popular resulting competitive products. Autocoat is now offering great opportunities to Indian manufacturers with such versatile Automatic Painting Machine
An Automatic Painting System has a Painting Booth composed of a partition having side Walls, a Ceiling, and a Floor which jointly define a working space isolated by the partition from exterior space for accommodating a work piece to be painted in a position therein. The partition has air inlet and outlet ports opening into the working space.
A movable painting mechanism such as a Automatic Spray Gun is disposed adjacent to the work piece position and controlled by a control unit disposed outside of the Painting Booth and including a Drive source. The control unit and the movable painting mechanism are interconnected by an arm accommodated in an arm housing extending through the partition with a sealing member hermetically sealing a gap between the arm housing and the partition.
Automatic Painting Machine should
High volumes Toy Painting Line or Toy Painting Line are very popular in China & vide rage of models are competively priced for good quality product. Autocoat have tie up with reputed companies from China, leading manufacturer for Automatic Painting Machine, Automatic Painting Lines, Auto Spray Painting Line without Robot, Portable Auto Painting Machine.
These machines can be added on with small air supply units and infrared and UV ovens. The basic need for automatic painting machine is that the quality of painting cannot be matched with manual spray painting, high production capacity can be achieved a comparatively less cost when compared with the painting practice in India.
These products are imported, tested as per international standards, and we stand in hand to hand with these products. Autocoat has tie up with Chinese Companies after careful evaluation considering following.
The Auto Spray Painting Machine or the Auto Spray Painting line is suitable for Plastic, ABS, FRP, etc that is we can also call this painting line as
Autocoat Engineering is the most experienced Painting Plant Manufacturer in India since last 40 years. Autocoat Engineering has been supplier Automatic Painting Machine in India among other valuable products. We have wide experience of manufacturing of Painting Plant with different material handling and different product size , and different production volume.
Automatic Painting Machine Supplier in India & Automatic Painting Machine Supplier in India
FAQ
Frequently Asked Questions
What is an automatic painting machine?
An automatic painting machine uses servo-driven reciprocators or robotic arms to apply paint with consistent overlap, gun-distance and film thickness — replacing manual operator spray for high-volume production. The result is uniform finish quality and lower paint consumption per part across thousands of components.
How does an automatic painting machine work?
PLC-controlled spray guns mounted on linear reciprocators or articulated robotic arms follow pre-programmed paint paths over the component as it moves on a conveyor at controlled speed. Trigger timing, gun speed, fan width and overlap are all pre-set per part program — ensuring identical results on every piece.
What components can be painted automatically?
Sheet metal panels, electrical enclosures and switchgear cabinets, automotive components, valve bodies, motor and alternator housings, fan blades, fitness equipment frames, two-wheeler frames and tanks, and any repetitive geometry component produced in volume where consistent finish quality is critical.
Is automatic painting better than manual?
For repetitive parts, yes — automatic painting gives uniform film thickness (±5 microns possible), 20–40% lower paint consumption, zero operator-to-operator variation and 3–5× higher throughput. Complex 3D parts with deep recesses may still need some manual touch-up for detail areas.
Can automatic machines paint complex shapes?
Yes. 5-axis articulated robotic arms handle complex 3D geometry. CAD-imported part programs (via DXF or STEP file import) let the machine paint intricate components like alternator housings, valve bodies, finned heat exchangers and contoured automotive parts with consistent coverage on every surface.
What is the production speed of automatic painting?
Typical line speeds are 0.5–2 m/min depending on part size, paint film requirements and number of guns. High-volume automatic painting lines deliver 200–500 painted components per shift versus 50–100 for manual booth operations — a 4–5× productivity improvement at consistent quality.
Are automatic painting machines programmable?
Yes. PLC and HMI control systems allow recipe storage for hundreds of different part programs with selection by HMI button or barcode scan. Programs can be created from CAD files via DXF or STEP file import, or built using teach-pendant manual learning where the operator demonstrates the path once.
Can existing paint shops add automatic painting?
Yes. Autocoat retrofits automatic spray reciprocator systems into existing dry-back, side-draft or downdraft paint booths — adding mounting rails, servo drives, control panel, HMI and pneumatic gun connections without replacing the booth structure. Cost-effective upgrade for plants modernising their paint shops.
What is the cost of an automatic painting machine?
The cost of an automatic painting machine varies depending on size, type, and automation. Key factors include axis count (2-axis to 5-axis), number of guns, controller specifications, software features (CAD import, recipe library), conveyor integration and any safety package. Contact us or send enquiry for exact cost.
Does Autocoat supply automatic painting machines in India?
Yes. Autocoat imports automatic painting machines from China and integrates them with our paint booths and ovens for high-volume Indian production lines. Each install includes mechanical erection, electrical conversion, programming, dry-run trials, paint validation and full operator training.
